UL263 testing photos

UL263 & BS EN 1364-1, vertical and horizontal, successful test photographs

The huge 5m x 5m frame prior to the FortaFire being installed for the two hour test
Button
The rig at UL ready for set up
Button
FortaFire installed ready for the 5m x 5m test to UL263 and BS EN 1364-1
Button
FortaFire FBI 120/90, flexible fire barrier, after a full 2 hour fire test successfully completed to UL263 for 120/55 and fully Certified to BS EN 1364-1 for 120/90
Button
Removal of the fire barrier rig after thest test in readiness for the fire hose application
Button
5 minute fire hose direct onto the FortaFire fire barrier, after the 2 hour fire test to UL263, 99.7% of the fire barrier remained intact, which is a massive achievement, bearing in mind this is usually undertaken on fire doors.
Button
Glowing red hot furnace after the full fire test
Button
TBAPS developed their own test rig to enable development of the FortaFire range alongside testing of each batch of material produced
Button
FortaFire FBI 120/60 after a successful indicative vertical test to UL263
Button
FortaFire FBI 120/60 installed ready for Horizontal Testing to UL263
Button
FortaFire FBI120/60 2nd lighweight layer being installed
Button
Mark Lineker, witness to test at UL, during both Vertical & Horizontal indicative testing
Button
Top Fixing, lightweight and easy to install, supplied as a kit
Button
Layers of fire barrier still intact after a successful test
Button
Fortafire FBI 120/60 after a successful horizontal test to UL263, achieving in excess of 120/60
